日本三丰数显卡尺500-163-30/500-754-20/500-193-30/378-713
Absolute Digimatic Caliper (500-163-30)
Exclusive Encoder Technology, Series 500, Inch/Metric
Part Number: 500-163-30
· ABSOLUTE electromagnetic induction linear encoder system is introduced (except for 0 - 300 mm/0 - 12" models).
· New ergonomic design with finger rest.
· The ZERO/ABS button allows the display to be Zero-Set at any slider position along the scale for comparison measurements. This button will also allow return to the absolute (ABS) mode and display of the true position from the origin (usually jaws closed point).
· Large and clear LCD readout.
· Smooth slider movement makes for comfortable operation.
· 18,000 hours battery life.
· Allows step measurement.
· Carbide-tipped jaw calipers are optimal for rough finished parts, castings, grinding stones, etc.
· Allows integration into statistical process control and measurement systems for models with measurement data output connector.
This is a series representative image of part number 500-178-30
Configured Specifications
Download
| Type | Standard caliper | Display Method | Digital |
|---|---|---|---|
| Measuring Range(mm) | 0 - 200 | Accuracy | ±.001” |
| Remark | Carbide-tipped jaws for OD measurement | Specification | Without SPC data output |
| Mass | 192 | Measuring Range(inch) | 0 - 8" |
| Instrumental Error(mm) | ±.001"/±0.02mm | - | - |
